DT06-12SB-CE13

The DT06-12SB-CE13 is a 12-position rectangular plug housing designed for female socket contacts, part of the DEUTSCH DT series from TE Connectivity. It is a wire-to-wire connector system with a free-hanging (in-line) mounting type. The housing is made of PA GF (glass-filled polyamide) and is black in color. It features a latch lock fastening system and is keyed for mating alignment. The connector is sealable and has an IP rating of IP6K9K and IP68, making it suitable for harsh environments. Electrical ratings include an operating voltage of 250 VDC and a maximum contact current rating of 13 A. The centerline pitch is 4.44 mm, with a row-to-row spacing of 9.12 mm. The housing accommodates size 16 contacts with a mating pin diameter of 1.59 mm. It has a cable exit angle of 180° and compatible insulation diameter range of 1.35 – 3.05 mm. The product dimensions are 43.21 mm length, 20.83 mm width, and 40.56 mm height. It is packaged in boxes of 350 units. The housing is RoHS and ELV compliant. It is designed for use in automotive and other demanding applications requiring a reliable sealed connection.
