| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Cord Length | |
| Current | |
| Efficiency | |
| Form | |
| Frequency | |
| Height | |
| Input Connector | |
| Input Type | |
| Input Voltage | |
| Length | |
| Mounting Type | |
| Operating Temperature | |
| Output Connector | |
| Output Voltage | |
| Overload Protection | |
| Polarization | |
| Power (Watts) | |
| Region Utilized | |
| Voltage | |
| Width |
The Artesyn Embedded Power DA16-120EU is a 16-watt AC/DC wall mount power supply designed for business-critical continuity. It accepts a universal AC input range of 90-264 Vac and provides a fully regulated 12.2V DC output.
Key electrical specifications include 75% typical efficiency at full load and 120 Vac input, with a voltage regulation of ±5% in constant voltage mode. The unit offers overload protection at 150% above maximum rating and auto-recovery for over-temperature conditions. It also features built-in EMI filtering compliant with CISPR 22 Class B standards.
Designed for ITE (Commercial) applications, this power supply meets CE Mark EMC & LVD requirements and is designed to meet Blue Angel standards and European Code of Conduct compliance. The output is delivered via a 2.1mm I.D. x 5.5mm O.D. barrel plug with positive center polarity.
Mechanical dimensions are 77.0mm x 53.0mm x 47.8mm. The operating temperature range is 0°C to 40°C ambient. The DA16-120EU has a demonstrated MTBF of over 550,000 hours at full load and 25°C.
The input voltage range is 90-264 Vac at 47-63 Hz.
It is a wall mount adapter with Class II construction, dimensions 77.0mm x 53.0mm x 47.8mm, and a 2.0m output cord with a barrel plug connector.
The operating temperature range is 0°C to 40°C.
The nominal output voltage is 12.2V with ±5% regulation.
It includes overload protection at 150% above maximum rating with auto recovery, and overtemperature protection with auto recovery.
It uses a barrel plug with 2.1mm inner diameter, 5.5mm outer diameter, 10.5mm length, and positive center polarity.
The demonstrated MTBF is greater than 550,000 hours at full load and 25°C ambient conditions.
