CY8C4247AZS-M485 The Infineon Technologies CY8C4247AZS-M485 is a microcontroller featuring an ARM Cortex-M0 core, 128KB of FLASH program memory, and 16KB of RAM. It operates at 48MHz and supports a voltage range of 1.71V to 5.5V.
Mfr Part #:

CY8C4247AZS-M485

Available from 1 distributors
Mfr Name: Infineon Technologies
Infineon Technologies
The Infineon Technologies CY8C4247AZS-M485 is a microcontroller featuring an ARM Cortex-M0 core, 128KB of FLASH program memory, and 16KB of RAM. It operates at 48MHz and supports a voltage range of 1.71V to 5.5V.
✓ Total Stock: 212,500 pcs

CY8C4247AZS-M485 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Components Technology Group, Inc. ✓
Non-Authorised Inventory information
212,500 pcs
On Request
212500 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

CY8C4247AZS-M485 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connectivity
Core Processor
Core Size
Data Converters
Frequency
Mounting Type
Number of I
Operating Temperature
Oscillator Type
Peripherals
Program Memory Size
Program Memory Type
RAM Size
Speed
Supplier Device Package
Tape & Reel
Voltage
View Similar Products (0)

CY8C4247AZS-M485 Description

Short technical summary and product information.

This Infineon Technologies CY8C4247AZS-M485 is a 32-bit microcontroller based on the ARM Cortex-M0 core, operating at a speed of 48MHz. It offers 128KB of FLASH program memory and 16KB of RAM, suitable for embedded applications.



The device supports a wide operating voltage range from 1.71V to 5.5V and features various peripherals including A/D and D/A converters, Cap Sense, PWM, and WDT. Connectivity options include CANbus, I²C, SPI, and UART.



Packaged in a 64-TQFP (10x10) format, this microcontroller is designed for surface mount applications. It operates within a temperature range of -40°C to 85°C (TA).

CY8C4247AZS-M485 Quick Information

Product Type: Microcontroller
Canonical Name: CY8C4247AZS-M485 Microcontroller
Subcategory: Embedded Microcontrollers

CY8C4247AZS-M485 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

CY8C4247AZS-M485 Features

  • ARM Cortex-M0 32-bit microcontroller core.
  • 128KB FLASH program memory.
  • 16KB RAM data memory.
  • 48MHz operating frequency.
  • 1.71V to 5.5V operating voltage range.

CY8C4247AZS-M485 Applications

  • Suitable for embedded control systems.
  • Features CANbus and LINbus connectivity.
  • Includes I2C, SPI, and UART interfaces.
  • Supports analog-to-digital conversion.

CY8C4247AZS-M485 FAQs

7 frequently asked questions generated from this part’s specifications.
What is the operating voltage for the CY8C4247AZS-M485?

The operating voltage is 1.71V to 5.5V.

What package type is the CY8C4247AZS-M485 supplied in?

It is supplied in a 64-TQFP (10x10) package.

What is the operating temperature range for this microcontroller?

The operating temperature range is -40°C to 85°C (TA).

Is the CY8C4247AZS-M485 RoHS compliant?

Yes, it is RoHS3 Compliant.

What is the program memory size of the CY8C4247AZS-M485?

The program memory size is 128KB (128K x 8).

What is the RAM size for this microcontroller?

The RAM size is 16K x 8.

What is the core processor of the CY8C4247AZS-M485?

The core processor is ARM Cortex-M0.
