This Cincon CQB50W8-36S24-CMFC is a 50 Watt isolated DC-DC converter designed for demanding applications. It features a wide 8:1 input voltage range of 9.5 to 75 VDC, with a nominal input of 36 VDC. The converter provides a regulated 24 VDC output at up to 2.08A.
Key electrical specifications include up to 90% efficiency and 3000Vac I/O isolation. The unit is fully protected against over-temperature (OTP), over-current (OCP), over-voltage (OVP), and under-voltage lockout (UVLO). It also includes a built-in EMI filter and remote On/Off control.
Designed for robust operation, the CQB50W8 series has an operating case temperature range of -40°C to +105°C with derating. Its mechanical dimensions are 116.8mm x 61.0mm x 32.0mm. The mounting type is chassis mount with an open frame construction, suitable for baseplate cooling.
Compliance includes UL62368-1 (2nd Edition, Reinforce Insulation), EN50155 for EMC, Environmental, and Characteristic, EN50155 (EN61373) for Shock & Vibration, and EN45545-2 for Fire & Smoke. Safety standards met are IEC/EN/UL 62368-1.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The input voltage range is 9.5 to 75 VDC.
The output voltage is 24 VDC and the maximum output current is 2.08 A.
The power rating is 50W.
The typical efficiency is 90%.
The operating temperature range is -40°C to +105°C, with derating.
It uses chassis mount with an open frame design.
