The CP2725AC54TEZ from ABB Power Electronics is a high-performance AC/DC converter belonging to the CP-Series. This front-end rectifier module is designed for rack mounting, featuring a 1U profile and a depth of 13.85 inches. It provides a regulated single-output voltage of 5V with an output current of 750 mA, delivering a total power of 2725W.
Key electrical specifications include a universal input voltage range and an impressive efficiency of 95%. The unit supports N+1 redundancy and hot-swap operation, along with features like active load sharing, remote on/off, and sense functions. It also includes dual I²C and RS485 interfaces for advanced control and monitoring.
This AC/DC converter is suitable for ITE (Commercial) applications and operates within a temperature range of -10°C to 75°C with derating. Compliance is indicated by CE approval. The CP2725AC54TEZ offers high power density, exceeding 40W/in³.
Applications include wireless/cellular infrastructure, energy systems, central office switching, PCS installations, bulk power for power architectures, and automatic test equipment.
-10°C to 75°C with derating.
Universal AC and a wide range of DC input voltage configurations.
95%.
Main output -54VDC and 5V standby output.
Rack Mount.
2725W.
2 outputs.
