TNY255GN/G
POWER
The TNY255GN/G is an offline switch IC from Power Integrations, designed for flyback converters. It features a 700V breakdown voltage and 6.5W maximum output power.
| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
6 pcs
|
6 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Mounting Type | |
| Operating Temperature |
The IXYS CMA50P1600FC is a dual SCR module belonging to the Power Driver Modules category. It is designed for applications requiring high voltage switching capabilities, with an off-state voltage rating of 1.6 kV.
This module offers a significant on-state current handling capacity, rated at 50 A average and 79 A RMS. Key electrical parameters include a gate trigger voltage (Vgt) maximum of 1.4 V and a gate trigger current (Igt) maximum of 80 mA. It can withstand non-repetitive surge currents of 720A and 780A at 50/60Hz, with a maximum holding current (Ih) of 100 mA.
The operating temperature range for this device is from -40°C to 150°C (TJ). It is housed in an i4-Pac™-5 package and utilizes a through-hole mounting type, facilitating integration into various electronic designs.
Compliance information indicates RoHS3 compliance, Moisture Sensitivity Level 1, and REACH unaffected status. The part number CMA50P1600FC is manufactured by IXYS.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The maximum off-state voltage is 1600 V.
The RMS on-state current is 79 A.
The operating temperature range is -40°C to 150°C.
The CMA50P1600FC module is mounted using the through-hole method.
The maximum gate trigger voltage is 1.4 V.
