| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,699,020 pcs
|
1699020 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Automotive Grade | |
| Current | |
| Impedance (Max) (Zzt) | |
| Mounting Type | |
| Operating Temperature | |
| Power | |
| SVHC Present | |
| Storage Temperature | |
| Supplier Device Package | |
| Tape & Reel | |
| Tolerance | |
| Voltage |
The Nexperia BZX384-C16-QX is a low-power voltage regulator diode from the BZX384-Q series, designed for surface-mount applications. It provides a nominal Zener voltage of 16V with a tolerance of ±5%, making it suitable for general regulation functions. The diode is rated for a maximum total power dissipation of 300mW at 25°C ambient temperature when mounted on a standard FR4 PCB.
Key electrical characteristics include a maximum forward voltage of 900mV at 10mA, a reverse leakage current of 50nA at 11.34V, and a typical impedance (Zzt) of 40Ω. The device can withstand a non-repetitive peak reverse power dissipation of up to 40W, enhancing its robustness in transient conditions. The junction temperature range extends to 150°C.
The BZX384-C16-QX is housed in a small SOD323 (SC-76) plastic package, which is leadless and suitable for automated assembly. It is qualified according to AEC-Q101, confirming its reliability for automotive applications. The part is RoHS compliant and REACH unaffected, though these certifications have not been independently verified in this data set.
| Qty | Low | High |
|---|---|---|
| 3,000+ | $0.04 | $0.04 |
| 9,000+ | $0.04 | $0.04 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The nominal Zener voltage is 16V.
Maximum total power dissipation is 300mW at 25°C ambient.
Maximum forward voltage is 900mV at 10mA.
It is supplied in a SOD-323 (SC-76) surface-mount package.
Yes, it is AEC-Q101 qualified.
Maximum reverse leakage current is 50nA at 11.34V.
Maximum junction temperature is 150°C.
