| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1 pcs
|
1 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Applications | |
| Current | |
| Current - Output 1 | |
| Efficiency | |
| Features | |
| Height | |
| Isolation Voltage | |
| Length | |
| Line Regulation | |
| Load Regulation | |
| MTBF | |
| Material Flammability | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage Adjustability | |
| Overvoltage Protection | |
| Package / Case | |
| Power (Watts) | |
| Ripple & Noise | |
| Ripple & Noise (RMS) | |
| Short circuit protection | |
| Switching Frequency | |
| Temperature Coefficient | |
| Transient Response | |
| Type | |
| Voltage | |
| Voltage - Input (Max) | |
| Voltage - Input (Min) | |
| Voltage - Output 1 | |
| Voltage Accuracy | |
| Weight | |
| Width |
The BXA40-48S05-M is an isolated DC/DC converter from Artesyn Embedded Power's BXA40 series, providing up to 40W of output power. It accepts a wide input voltage range of 36V to 75V DC and delivers a regulated 5V output at 8A with a typical efficiency of 82%. The converter operates at a fixed switching frequency of 350kHz and features 1500V DC input/output isolation. It includes overvoltage protection (135% of Vout), continuous short circuit protection, remote sense, and output voltage trim capability (±10%).
The converter comes in a 9-DIP through-hole package measuring 55.9mm x 55.9mm x 12.7mm and weighing 85g. It is designed for an operating temperature range of -40°C to 105°C with a temperature coefficient of ±0.02%/°C. The module meets EMC immunity standards EN61000-4-2, -3, -4, -5, -6 and has conducted emissions compliance to EN55022 and FCC Part 15 Level B. It also carries safety approvals for EN60950, CSA C22.2 No. 950, and UL1950.
Typical applications include telecommunications equipment, industrial electronics, test equipment, mobile telecommunications, and distributed power architectures. The 48V input models are particularly suited for telecom applications meeting ETSI standard ETS300-132-2. The module has a calculated MTBF of 500,000 hours per MIL-HDBK-217F.
36V to 75V DC.
5V at 8A.
9-DIP Module, through-hole mounting.
-40°C to 105°C.
Yes, it is RoHS3 compliant (unverified from source).
82% typical.
1500V DC.
