| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
187,020 pcs
|
187020 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
17 pcs
|
17 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Automotive Grade | |
| Current | |
| Drain to Source Voltage (Vdss) | |
| Drive Voltage (Max Rds On, Min Rds On) | |
| FET Type | |
| Input Capacitance (Ciss) (Max) @ Vds | |
| Junction Temperature | |
| Mounting Type | |
| Operating Temperature | |
| Power Dissipation (Max) | |
| Rds On (Max) @ Id, Vgs | |
| Storage Temperature | |
| Supplier Device Package | |
| Tape & Reel | |
| Technology | |
| Vgs (Max) | |
| Vgs(th) (Max) @ Id |
The BUK98180-100A/CUX is a logic level N-channel enhancement mode Field-Effect Transistor manufactured by Nexperia using TrenchMOS technology. It is designed for automotive applications and qualified to AEC-Q101 standards.
The device features a drain-source voltage rating of 100V and a continuous drain current rating of 4.6A at 25°C. On-state resistance is typically 147 mΩ at VGS = 10V and ID = 5A, with a maximum of 173 mΩ. The gate threshold voltage is a maximum of 2V at ID = 1 mA, making it suitable for logic level gate drive sources.
Additional electrical characteristics include a peak drain current of 18A and a non-repetitive avalanche energy rating of 16 mJ. Input capacitance is 619 pF at VDS = 25V. The device is housed in a surface-mount SC-73 (SOT223) package with four leads and operates over a junction temperature range of -55°C to 150°C.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.25 | $1.25 |
| 10+ | $0.87 | $0.87 |
| 100+ | $0.55 | $0.55 |
| 500+ | $0.34 | $0.34 |
| 1,000+ | $0.25 | $0.25 |
| 2,000+ | $0.22 | $0.22 |
| 5,000+ | $0.19 | $0.19 |
| 10,000+ | $0.17 | $0.17 |
| 25,000+ | $0.14 | $0.14 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The maximum drain-source voltage rating is 100 V.
The continuous drain current is 4.6 A at Tsp = 25°C with VGS = 5 V.
The package is SC-73 (SOT223), a surface-mount package with four leads and an increased heatsink.
The junction temperature range is -55°C to 150°C.
Yes, it is AEC-Q101 qualified for automotive applications as confirmed by the manufacturer datasheet.
The typical Rds(on) is 147 mΩ at VGS = 10V, ID = 5A, Tj = 25°C.
