The Weidmüller BR1D15UC is a thermal magnetic miniature circuit breaker designed for reliable branch circuit protection. It offers a 15A current rating and a 277V voltage rating, suitable for AC/DC applications.
This circuit breaker is designed for DIN rail mounting, facilitating easy installation in control panels and enclosures. Its 1-pole configuration makes it ideal for single-phase circuits or specific DC applications. The thermal magnetic tripping mechanism provides overcurrent and short-circuit protection.
Key specifications include a 15A current rating and a 277V voltage rating. The breaker is approved by agencies such as CE, CSA, TUV, UL489, and VDE, indicating compliance with relevant safety standards. It is also RoHS3 compliant and has an MSL of 1.
Applications for this circuit breaker include protecting wiring and cables from device malfunctions in industrial environments. Its robust construction and adherence to multiple safety standards make it a dependable choice for various power distribution and control systems.
277V AC/DC.
15A.
Thermal magnetic miniature circuit breaker.
1 pole.
DIN rail.
CE, CSA C22.2 No 5, CSA C22.2 No 235, TUV, UL489, VDE.
Lever.
