The Bel Power Solutions BPD1003 backplane is an accessory for the T Series of AC-DC converters. It facilitates the fast and simple setup of 19" rack-mounted power supply systems, including telecom rectifiers, battery chargers, and modular power bus systems. This backplane supports n+1 redundancy configurations.
Key features include a maximum power output of 1.6 kW, accommodating up to three T Series converters. It is designed for single or triple phase input connections. The backplane concept allows for easy system assembly and expansion under load by simply inserting additional T units. Monitoring signals and control inputs/outputs are accessible via a screw terminal strip, and system-specific signal combinations are possible with jumper settings, enabling the backplane to function as a controller unit.
This accessory is engineered to optimize the performance and installation of compatible power supplies, providing reliable and adaptable power solutions for diverse applications. It is suitable for systems requiring easy configuration and potential for expansion.
The BPD1003 backplane supports a maximum power output of 1.6 kW.
The BPD1003 backplane supports single or triple phase input connections.
The BPD1003 backplane is RoHS3 Compliant.
The Moisture Sensitivity Level (MSL) for the BPD1003 backplane is 1 Unlimited.
The BPD1003 backplane is REACH Unaffected.
