BC857B,215 Nexperia BC857B,215 is a PNP general-purpose transistor rated for 45V collector-emitter voltage and 100mA collector current. It comes in a surface-mount SOT23 (TO-236AB) package.
Mfr Part #:

BC857B,215

Available from 3 distributors
Mfr Name: Nexperia USA Inc.
Nexperia USA Inc.
Nexperia BC857B,215 is a PNP general-purpose transistor rated for 45V collector-emitter voltage and 100mA collector current. It comes in a surface-mount SOT23 (TO-236AB) package.
✓ Total Stock: 13,397,516 pcs
$ Price Range: $0.02 - $0.21

BC857B,215 Available from 3 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Optech Co.,Limited ✓
Non-Authorised Inventory information
13,396,020 pcs
On Request
13396020 pcs On Request 1 On Request On Request On Request On Request On Request
Braun Electronic Components ✓
Non-Authorised Inventory information
1,331 pcs
On Request
1331 pcs On Request 1 On Request On Request On Request On Request On Request
Bristol Electronics ✓
Non-Authorised Inventory information
165 pcs
On Request
165 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

BC857B,215 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Current
DC Current Gain (hFE) (Min) @ Ic, Vce
Frequency
Mounting Type
Operating Temperature
Power
Storage Temperature
Supplier Device Package
Tape & Reel
Termination Style
Transistor Type
Vce Saturation (Max) @ Ib, Ic
Voltage
View Similar Products (0)

BC857B,215 Description

Short technical summary and product information.

The Nexperia BC857B,215 is a PNP general-purpose bipolar junction transistor designed for low-voltage, low-current switching and amplification applications. It features a maximum collector-emitter voltage of 45V and a maximum collector current of 100mA, with a peak current capability of 200mA.



This transistor offers a DC current gain (hFE) of 220 to 475 at 5V and 2mA, ensuring consistent performance in linear amplification stages. The transition frequency (ft) is typically 100MHz, making it suitable for audio and low-frequency signal processing. The maximum power dissipation is 250mW on an FR4 PCB at 25°C ambient.



Housed in a small SOT23 (TO-236AB) surface-mount package, the BC857B is ideal for space-constrained designs. It is the PNP complement to the Nexperia BC847B NPN transistor, enabling complementary circuit topologies. The device is part of the BC857 series, which includes gain group variants BC857A, BC857B, and BC857C.

BC857B,215 Quick Information

Product Type: Bipolar Junction Transistor (BJT)
Series: BC857
Canonical Name: Nexperia BC857B PNP General-Purpose Transistor
Subcategory: General-Purpose Transistor

BC857B,215 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

BC857B,215 Estimated Pricing

Qty Low High
1+ $0.21 $0.21
10+ $0.08 $0.08
100+ $0.05 $0.05
500+ $0.03 $0.03
1,000+ $0.03 $0.03
3,000+ $0.02 $0.02

Estimated market price range - modelled values for guidance only, not live distributor offers.

BC857B,215 Features

  • PNP general-purpose bipolar junction transistor.
  • Rated for 45V collector-emitter voltage.
  • Supports 100mA continuous collector current.
  • DC current gain of 220 to 475.
  • Surface-mount SOT23 (TO-236AB) package.

BC857B,215 Applications

  • General-purpose switching circuits.
  • Signal amplification in audio stages.
  • Complementary driver stages with BC847B.
  • Low-power consumer electronics.

BC857B,215 FAQs

7 frequently asked questions generated from this part’s specifications.
What is the maximum collector-emitter voltage for the BC857B?

The maximum collector-emitter voltage (VCEO) is 45V with the base open.

What is the maximum collector current of the BC857B?

The maximum continuous collector current is 100mA, with a peak current of 200mA.

What is the package type for the BC857B,215?

The package is SOT23 (TO-236AB), a surface-mount package with 3 leads.

What is the operating junction temperature range for this transistor?

The maximum junction temperature is 150°C.

What is the DC current gain (hFE) of the BC857B?

The DC current gain is 220 to 475 at VCE = 5V and IC = 2mA.

What is the transition frequency of the BC857B?

The typical transition frequency (ft) is 100 MHz.

What is the NPN complement to the BC857B?

The NPN complement is the BC847B.
