| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
91,020 pcs
|
91020 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Automotive Grade | |
| Current | |
| DC Current Gain (hFE) (Min) @ Ic, Vce | |
| Frequency | |
| Mounting Type | |
| Operating Temperature | |
| Pitch | |
| Power | |
| SVHC Present | |
| Storage Temperature | |
| Supplier Device Package | |
| Tape & Reel | |
| Transistor Type | |
| Vce Saturation (Max) @ Ib, Ic | |
| Voltage |
The BC847BPN-QF from Nexperia is a NPN/PNP general-purpose transistor pair housed in a very small SOT363 (SC-88) surface-mount plastic package. It offers a maximum collector-emitter voltage of 45 V and a maximum collector current of 100 mA per transistor. The DC current gain ranges from 200 to 450 at VCE = 5 V and IC = 2 mA, ensuring closely matched gain for the two transistors.
This device features low collector-emitter saturation voltage (300 mV max at 5 mA base current and 100 mA collector current) and low collector capacitance, making it suitable for general-purpose switching and amplification. The dual-transistor configuration reduces component count and board space while eliminating mutual interference between the transistors.
The BC847BPN-QF is qualified to AEC-Q101 and recommended for automotive applications. It is supplied in a 6-lead TSSOP6 (SOT-363) package with a 0.65 mm pitch and body dimensions of 2.1 mm x 1.25 mm x 0.95 mm. The operating junction temperature range is -65 to 150 °C.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.27 | $0.27 |
| 10+ | $0.16 | $0.16 |
| 100+ | $0.10 | $0.10 |
| 500+ | $0.07 | $0.07 |
| 1,000+ | $0.06 | $0.06 |
| 2,500+ | $0.05 | $0.05 |
| 5,000+ | $0.05 | $0.05 |
| 10,000+ | $0.05 | $0.05 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The maximum collector-emitter voltage is 45 V per transistor (open base).
It is available in a 6-TSSOP, SC-88, or SOT-363 surface-mount package. The supplier device package is 6-TSSOP (SOT-363).
The ambient temperature range is -65 to 150 °C, and the storage temperature range is the same.
It is listed as RoHS3 compliant, but this is unverified and based on low-confidence data.
The DC current gain ranges from 200 to 450 at VCE = 5 V and IC = 2 mA at 25 °C.
The maximum collector current is 100 mA, with a peak collector current of 200 mA.
Yes, it is AEC-Q101 qualified as per the datasheet.
