| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
354 pcs
|
354 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Retention (Minimum @ Size 12) | |
| Contact Retention (Minimum @ Size 16) | |
| Contact Retention (Minimum @ Size 20) | |
| Current Rating (Nominal @ Size 12) | |
| Current Rating (Nominal @ Size 16) | |
| Current Rating (Nominal @ Size 20) | |
| Dielectric Strength | |
| Fastening Type | |
| Features | |
| Ingress Protection | |
| Insulation Resistance | |
| Moisture Resistance | |
| Mounting Feature | |
| Mounting Type | |
| Number of Positions | |
| Operating Temperature | |
| Orientation | |
| Ozone Resistance | |
| Primary Material | |
| Shell Finish | |
| Shell Material | |
| Shell Size | |
| Shielding | |
| Shock | |
| Temperature Life | |
| Termination | |
| Thermal Shock | |
| durability (Minimum @ Bayonet coupling) | |
| durability (Minimum @ Threaded coupling) | |
| vibration (Minimum @ MMB / Self-Lock random) | |
| vibration (Minimum @ Standard sinusoidal) |
The BACC45FN12C12P is a circular connector assembly from Cinch, part of the BACC45 series qualified to MIL-C-26500. It features a receptacle with male pins, 12 power positions, and gold-plated contacts for reliable conductivity. The connector uses crimp termination and a bayonet lock coupling for secure mating. It is designed for panel mounting with a flange and includes a cable clamp feature. The shell is made of anodized aluminum, providing durability and corrosion resistance. Environmentally sealed, it offers ingress protection against moisture and contaminants. Electrical ratings include current capacities of 7.5A for size 20 contacts, 13A for size 16, and 23A for size 12, with a dielectric strength of 1500 VAC RMS and insulation resistance of 5000 MΩ minimum. The connector operates over a wide temperature range from -55°C to 200°C and withstands thermal shock, vibration up to 20 g, and shock of 50 g. It is suitable for aerospace, military, and industrial applications requiring high reliability in harsh environments.
12 power positions.
7.5A for size 20 contacts, 13A for size 16, and 23A for size 12.
Panel mount with flange.
-55°C to 200°C.
Yes, environment sealed.
Aluminum shell with anodized finish.
Bayonet lock.
