AWHW 10G-SMD-R The Assmann WSW Components AWHW 10G-SMD-R is a 10-pin male header connector designed for SMT mounting. It features a 2.54mm contact spacing and a 3A current rating.
Mfr Part #:

AWHW 10G-SMD-R

Available from 1 distributors
Mfr Name: Assmann WSW Components
Assmann WSW Components
The Assmann WSW Components AWHW 10G-SMD-R is a 10-pin male header connector designed for SMT mounting. It features a 2.54mm contact spacing and a 3A current rating.
✓ Total Stock: 450 pcs
$ Price Range: $0.10

AWHW 10G-SMD-R Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Seba Components ✓
Non-Authorised Inventory information
450 pcs
On Request
450 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

AWHW 10G-SMD-R Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Contact Type
Current Rating
Insulator Material
Mounting Type
Plating
View Similar Products (0)

AWHW 10G-SMD-R Description

Short technical summary and product information.

This AWHW 10G-SMD-R from Assmann WSW Components is a male header connector belonging to the DIN 41651 product group. It is designed for surface mount technology (SMT) with a straight contact direction.



The connector has 10 pins with a standard contact spacing of 2.54mm. The current rating for this header is 3.0A. The insulator material is PA6T, rated UL94V-0, and the contacts are plated with Gold selective Tin.



This component is suitable for various electronic applications requiring reliable connections. Its SMT mounting type allows for automated assembly processes on printed circuit boards.

AWHW 10G-SMD-R Quick Information

Product Type: Header Connector
Series: AWHW
Canonical Name: AWHW 10G-SMD-R Header Male SMT Connector
Subcategory: Header

AWHW 10G-SMD-R Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

AWHW 10G-SMD-R Estimated Pricing

Qty Low High
1+ $0.10 $0.10

Estimated market price range - modelled values for guidance only, not live distributor offers.

AWHW 10G-SMD-R Features

  • 10-pin male header connector
  • 2.54mm contact spacing
  • 3A current rating
  • SMT mounting type
  • Gold selective Tin plating

AWHW 10G-SMD-R Applications

  • Used in electronic circuit assemblies
  • Suitable for high-volume SMT manufacturing
  • Ideal for applications requiring reliable contact
  • Suitable for automation and PCB mounting

AWHW 10G-SMD-R FAQs

5 frequently asked questions generated from this part’s specifications.
What is the pin count of the AWHW 10G-SMD-R?

The AWHW 10G-SMD-R has 10 pins.

What is the contact spacing for the AWHW 10G-SMD-R?

The contact spacing is 2.54 mm.

What is the current rating of the AWHW 10G-SMD-R?

The current rating is 3 A.

What type of mounting does the AWHW 10G-SMD-R use?

The AWHW 10G-SMD-R uses SMT mounting.

What is the plating material on the AWHW 10G-SMD-R contacts?

The contacts are plated with Gold selective Tin.
