Mfr Part #:

AW33901FCR

Mfr Name: Awinic

The AWINIC AW33901FCR is a surge protection IC designed for over-voltage protection. It offers a default OVP threshold of 5.95V and a surge protection rating of 30V.

✓ Total Stock: 2,863 pcs

$ Price Range: $0.11

AW33901FCR Available from 2 distributors

✓ Authorised

✓ Non-Authorised

Distributor		Stock	Pricing	MOQ	PKG	Lead Time	Date Code	On Order Quantity	On Order Delivery
Rayichip ✓ Non-Authorised Inventory information	2,491 pcs On Request	2491 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request
Optech Co.,Limited ✓ Non-Authorised Inventory information	372 pcs On Request	372 pcs	On Request	1	On Request	On Request	1828+	On Request	On Request

AW33901FCR Specifications Quick View

Most important parameters for selection – full specs in datasheet.

SELECT ALL

Category	New Products
Manufacturer Name	Awinic
Mounting Type	Surface Mount
Number of Pins	9
Operating Temperature	-40℃~85℃
Storage Temperature	°C ~ °C
Tape & Reel	No

View Similar Products (0)

AW33901FCR Description

Short technical summary and product information.

The AWINIC AW33901FCR is an integrated circuit designed for surge protection and over-voltage protection (OVP) applications. It features a default OVP threshold of 5.95V, with an adjustable range from 4V to 20V, allowing for flexible system design.

This device offers robust protection with a surge protection rating of 30V and a continuous current capability of up to 5A through the switch. The integrated low Rdson nFET switch has a typical resistance of 30mΩ. It also includes a 20V input DC withstand voltage and a fast OVP response time of 50ns.

The AW33901FCR operates within a temperature range of -40°C to 85°C and supports an IO level of 1.8V. It is housed in a compact 1.2mm x 1.2mm FCQFN package with 9 pins, suitable for surface-mount technology (SMT).

This component is part of AWINIC's power management solutions, specifically within their over-voltage protection product line. Its features make it suitable for various electronic devices requiring protection against voltage transients.

AW33901FCR Quick Information

Product Type: Surge Protection IC

Series: Over-Voltage Protection

Canonical Name: AWINIC AW33901FCR Surge Protection IC

Subcategory: Over-Voltage Protection

AW33901FCR Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

AW33901FCR Estimated Pricing

Qty	Low	High
1+	$0.11	$0.11

Estimated market price range - modelled values for guidance only, not live distributor offers.

AW33901FCR Features

Integrated surge and over-voltage protection.
Default 5.95V OVP threshold.
Adjustable OVP range from 4V to 20V.
5A continuous current capability.
Compact 1.2mm x 1.2mm FCQFN package.

AW33901FCR Applications

Protects sensitive electronic circuits.
Suitable for power management systems.
Used in consumer electronics devices.
Ideal for battery-powered applications.

AW33901FCR FAQs

7 frequently asked questions generated from this part’s specifications.

What is the default Over-Voltage Protection (OVP) threshold for the AW33901FCR?

The default OVP threshold for the AW33901FCR is 5.95V.

What is the adjustable range for the OVP threshold on the AW33901FCR?

The OVP threshold can be adjusted from 4V to 20V.

What is the maximum surge protection voltage for the AW33901FCR?

The surge protection voltage is rated at 30V.

What is the maximum continuous current the AW33901FCR can handle?

The continuous current capability of the switch IN-OUT is a maximum of 5A.

What is the typical on-resistance of the AW33901FCR's switch?

The typical on-resistance (Ron) of the integrated nFET switch is 30mΩ.

What is the operating temperature range for the AW33901FCR?

The operating temperature range is from -40°C to 85°C.

What package type is the AW33901FCR available in?

The AW33901FCR is available in a 1.2mm x 1.2mm FCQFN package with 9 pins.
