The Aimtec AMEL15-9SJZ-105 is an enclosed AC/DC converter with a power output of 15W and a single 9V output voltage. It accepts a universal input voltage range of 85-264VAC or 100-370VDC, making it suitable for various power grid and industrial applications.
This converter operates within a temperature range of -40°C to 70°C, with derating at higher temperatures. It offers a high isolation voltage of 4000VAC for enhanced system safety and reliability. Key protection features include output short circuit, over-current, and over-voltage protection.
Designed for through-hole mounting, the AMEL15-9SJZ-105 comes in a 4-DIP Module package. Its efficiency is rated at 77% at 230VAC. The series is compliant with standards such as 60950-1 and 62368-1, and carries CE, cULus, and cURus agency approvals.
The input voltage range is 85-264VAC and 100-370VDC.
The output voltage is 9V.
The maximum output current is 1.66A.
The power rating is 15W.
The operating temperature range is -40°C to 70°C.
It uses a 4-DIP Module package.
Yes, it includes output short circuit, over-current, and over-voltage protection.
