The Aimtec AME25-12SJZ is an enclosed AC/DC converter designed for ITE (Commercial) applications. It provides a single 12V output with a maximum current of 2.1A, delivering up to 25W of power.
Key electrical specifications include an input voltage range of 85-305 VAC or 100-430 VDC, and an efficiency of 83%. The converter offers a voltage adjustment range of ±10% and features protections such as over-current and over-voltage protection. It also includes I/O isolation of 3000 VAC.
This converter is designed for Through Hole mounting and comes in a 6-DIP Module package. It operates within a temperature range of -40°C to 70°C (with derating) and has a typical MTBF of over 300,000 hours. The unit is CE and cURus approved.
85-305 VAC or 100-430 VDC
12V at 2.1A maximum
6-DIP Module with Through Hole mounting
-40°C to +70°C with derating
25 W
Auto recovery
65 KHz
