| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage | |
| Power (Watts) | |
| Storage Temperature | |
| Temperature Coefficient | |
| Type | |
| Voltage | |
| Width |
The Aimtec AME20-3.3SBJZ is an enclosed AC/DC converter designed for ITE (Commercial) applications. It delivers a 3.3V output voltage at a maximum current of 3.6A, providing up to 12W of power.
This converter features a wide input voltage range of 90-528 VAC or 100-745 VDC, making it versatile for various power sources. It boasts a typical efficiency of 74% at 230 VAC and offers essential protections including over-current and over-voltage protection. The isolation rating between input and output is 4000 VAC.
Designed for Through Hole mounting, the AME20-3.3SBJZ comes in a 5-DIP Module, 4 Leads package. It operates within a temperature range of -40°C to +70°C with derating. The dimensions are 70.0mm x 48.0mm x 30.0mm.
The input voltage range is 90-528 VAC (47-63 Hz) or 100-745 VDC.
The maximum output power is 12 W.
-40°C to +70°C.
4000 VAC for 60 seconds.
74% at 230 VAC.
5-DIP Module, 4 Leads, with dimensions 70.0 x 48.0 x 30.0 mm.
Over current (130-400% of Iout), over voltage (7.5 VDC clamp for 3.3Vout), and short circuit protection (hiccup, auto recovery).
