| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
89 pcs
|
89 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Adapter Series | |
| Adapter Type | |
| Center Contact Plating | |
| Center Gender | |
| Conversion Type | |
| Convert From (Adapter End) | |
| Convert To (Adapter End) | |
| Fastening Type | |
| Frequency | |
| Frequency - Max | |
| Impedance | |
| Material | |
| Mounting Type | |
| SVHC Present | |
| Style | |
| Tape & Reel | |
| VSWR (Minimum @ 20 - 26.5 GHz) | |
| VSWR (Minimum @ DC - 20 GHz) | |
| VSWR (Typical @ 26.5 - 30 GHz) |
The ADT-2735-FF-3MM-02 is a 3.5mm female to female in-series RF adapter from Cinch Connectivity Solutions. It features a straight, jack-to-jack configuration with threaded fastening on both ends. The adapter is designed for free hanging (in-line) mounting and is constructed from stainless steel with gold-plated center contacts.
Electrical specifications include a 50 Ohm impedance and a maximum frequency of 26.5 GHz (with datasheet indicating 30 GHz capability). VSWR is 1.10:1 minimum from DC to 20 GHz, 1.15:1 minimum from 20 to 26.5 GHz, and 1.20:1 typical from 26.5 to 30 GHz. The adapter is 100% swept frequency tested for consistent performance.
This adapter is suitable for high-end commercial, laboratory, test and measurement, and military applications. Its rugged stainless steel construction ensures durability in demanding environments. The compact in-line design minimizes signal loss and maintains impedance matching.
| Qty | Low | High |
|---|---|---|
| 1+ | $103.83 | $103.83 |
| 10+ | $88.25 | $88.25 |
| 25+ | $82.73 | $82.73 |
| 50+ | $78.79 | $78.79 |
| 100+ | $75.03 | $75.03 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
50 Ohms.
DC to 26.5 GHz (datasheet indicates 30 GHz operation).
VSWR is 1.10:1 minimum from DC to 20 GHz, 1.15:1 minimum from 20 to 26.5 GHz, and 1.20:1 typical from 26.5 to 30 GHz.
3.5mm female to female (jack to jack).
Free hanging (in-line).
Stainless steel body with gold-plated center contacts.
RoHS3 compliant (unverified).
