| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
80 pcs
|
80 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Adapter Series | |
| Adapter Type | |
| Approval Agency | |
| Center Contact Plating | |
| Center Gender | |
| Contact Material | |
| Conversion Type | |
| Convert From (Adapter End) | |
| Convert To (Adapter End) | |
| Dielectric Material | |
| Fastening Type | |
| Frequency | |
| Frequency Range | |
| Housing Material | |
| Impedance | |
| Mounting Type | |
| SVHC Present | |
| Style | |
| VSWR (Maximum @ 4.0 to 8.0 GHz) | |
| VSWR (Maximum @ 8.0 to 18.0 GHz) | |
| VSWR (Maximum @ DC to 4.0 GHz) |
The Cinch ADT-2712-NM-3MM-02 is a between series coaxial adapter designed to connect a 3.5mm plug to an N plug. It is a straight, plug-to-plug adapter with threaded coupling on both ends, ensuring secure connections in RF systems.
This adapter offers 50 Ohm impedance and operates from DC to 18 GHz, making it suitable for a wide range of microwave applications. VSWR is specified as 1.04:1 maximum from DC to 4 GHz, 1.07:1 from 4 to 8 GHz, and 1.12:1 from 8 to 18 GHz, ensuring excellent signal integrity across the band.
Constructed with a passivated stainless steel housing and gold plated beryllium copper center contacts, the adapter provides durability and reliable electrical performance. The dielectric is PTFE (Teflon), and the mounting style is free hanging (in-line). The adapter is RoHS3 compliant.
| Qty | Low | High |
|---|---|---|
| 1+ | $151.93 | $151.93 |
| 10+ | $129.15 | $129.15 |
| 25+ | $121.07 | $121.07 |
| 50+ | $115.30 | $115.30 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
50 Ohm.
DC to 18 GHz.
Maximum VSWR is 1.04:1 from DC to 4 GHz, 1.07:1 from 4 to 8 GHz, and 1.12:1 from 8 to 18 GHz.
Between series adapter converting from a 3.5mm plug to an N plug, plug to plug, straight.
Housing: stainless steel passivated; center contact: gold plated beryllium copper; dielectric: PTFE (Teflon).
Yes, RoHS3 compliant per datasheet.
Free hanging (in-line) with threaded fastening on both ends.
