| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
30 pcs
|
30 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Adapter Series | |
| Adapter Type | |
| Center Contact Plating | |
| Center Gender | |
| Conversion Type | |
| Convert From (Adapter End) | |
| Convert To (Adapter End) | |
| Fastening Type | |
| Frequency | |
| Impedance | |
| Mounting Type | |
| Style |
The Cinch ADT-2672-BF-SMM-02 is a between series coaxial adapter designed to connect a BNC female connector to an SMA male connector. It supports 50 Ohm systems and is rated for frequencies up to 8 GHz, making it suitable for a wide range of RF applications.
The adapter features a straight body design with free hanging in-line mounting. The BNC side uses a bayonet lock for quick connection, while the SMA side uses threaded coupling for a secure, vibration-resistant fit. Center contacts are gold plated to ensure low resistance and corrosion resistance.
This adapter is commonly used in test and measurement, telecommunications, and broadcast equipment where interconnecting BNC and SMA interfaces is required. Its compact straight design minimizes signal degradation and maintains impedance matching.
| Qty | Low | High |
|---|---|---|
| 1+ | $107.33 | $107.33 |
| 10+ | $107.32 | $107.32 |
| 50+ | $105.65 | $105.65 |
| 100+ | $102.49 | $102.49 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
Free hanging (in-line) mounting.
50 Ohm.
Up to 8 GHz.
BNC Jack (female socket) to SMA Plug (male pin).
Bayonet lock on BNC side, threaded on SMA side.
Gold.
Straight.
