The Weidmüller AD-TX-EM01 is a supply module specifically designed for the ESX10-T electronic circuit protection system. This module facilitates selective disconnection of 24VDC load systems, responding faster to overloads than traditional switch-mode power supplies due to active current limitation.
Key features include adjustable current ratings ranging from 0.5A to 12A, allowing for tailored protection. It supports capacitive loads up to 20,000 µF, ensuring safe connection even with inrush currents. The module is designed for rail mounting, with a width of only 12.5mm per unit, making it suitable for space-constrained applications.
Status and failure indication are provided, and remote operation is possible via reset or ON/OFF control signals. The manual ON/OFF button allows for individual circuit actuation and reset. This accessory enhances the reliability and selectivity of 24VDC power distribution systems by isolating faults to specific load circuits.
The current ratings for the AD-TX-EM01 range from 0.5 A to 12 A.
The AD-TX-EM01 supports capacitive loads up to 20,000 µF.
The width of the AD-TX-EM01 module is 12.5 mm.
The AD-TX-EM01 is designed for rail mounting.
