The ACMD-6125-TR1, manufactured by Broadcom Inc. (formerly Avago Technologies), is an RF Duplexer designed for applications requiring efficient signal separation. It covers a frequency range from 1.85GHz to 1.915GHz for one band and 1.93GHz to 1.995GHz for another, ensuring robust performance in mobile communication systems.
This duplexer exhibits significant return loss, with minimum values of 44.0dB and 48.0dB, and maximum values reaching up to 70.0dB and 67.0dB respectively. The insertion loss is kept low, typically at 9.0dB and 8.0dB, contributing to overall system efficiency. The component is designed for surface mount applications and comes in a 9-SMD package, suitable for integration into compact PCB designs.
Its design aims to prevent interference between transmit and receive signals, crucial for maintaining clear communication channels in base stations and other wireless infrastructure. The ACMD-6125-TR1 is engineered to provide reliable performance and high isolation, making it a suitable choice for demanding RF applications.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.76 | $1.76 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The ACMD-6125-TR1 operates in two frequency bands: 1.85GHz to 1.915GHz and 1.93GHz to 1.995GHz.
The return loss specifications are a minimum of 44.0dB and a maximum of 70.0dB for one band, and a minimum of 48.0dB and a maximum of 67.0dB for the other band.
The typical insertion loss for the ACMD-6125-TR1 is 9.0dB and 8.0dB.
The ACMD-6125-TR1 is in a 9-SMD package.
The ACMD-6125-TR1 is a surface mount device.
