| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
78 pcs
|
78 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Actuator Level | |
| Actuator Type | |
| Circuit | |
| Current Rating (Amps) | |
| Height Above Board | |
| Length | |
| Mounting Type | |
| Number of Positions | |
| Operating Temperature | |
| Pitch | |
| Termination Style | |
| Voltage Rating | |
| Washable |
This Omron A6SN-3101-P is a slide-actuated DIP switch designed for surface mount applications. It operates with an SPST circuit configuration and is rated for a current of 25mA at 24VDC.
The switch features gull wing termination style and a pitch of 2.54mm (0.100"). It has a height above board of 4.45mm and an operating temperature range of -30°C to 85°C. The actuator level is flush or recessed, and the switch is washable.
This component is suitable for various electronic control and switching applications where space-saving and reliable actuation are required. Its surface mount design facilitates automated assembly processes.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.75 | $0.75 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The operating voltage for the A6SN-3101-P is 24VDC.
The operating temperature range is -30°C to 85°C.
The A6SN-3101-P uses a surface mount type.
The current rating is 25mA.
The circuit type is SPST.
The A6SN-3101-P has 3 positions.
