| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating (Amps) | |
| Mounting Type | |
| Number of Poles | |
| Operating Temperature | |
| Voltage Rating |
The Weidmüller 9926253550 is a hydraulic magnetic circuit breaker designed for reliable circuit protection. This 3-pole unit operates at 480V and has a current rating of 50A.
Key electrical specifications include a 10,000A interrupting capacity and an operating life of 10,000 mechanical operations. The breaker is designed for a wide operating temperature range of -40°C to +65°C.
For mechanical installation, the 9926253550 features a DIN rail mounting type, making it suitable for standard industrial control panels. The actuator type is a lever for manual operation.
This circuit breaker is approved by CE, CSA C22.2 No 235, UL1077, and VDE, ensuring compliance with various industry standards. It is also RoHS3 Compliant, has an MSL of 1, and is REACH Unaffected.
The circuit breaker is rated for 480VAC.
The continuous current rating is 50A.
It uses a magnetic hydraulic delay (hydraulic-magnetic) trip mechanism.
It is a 3-pole circuit breaker.
It mounts on DIN rail.
The operating temperature range is -40°C to +65°C.
It is approved by CE, CSA C22.2 No 235, UL1077, and VDE.
