| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Operating Temperature | |
| Torque | |
| Voltage Rating |
The Weidmüller 9926 Series circuit breaker, part number 9926253530, is a 3-pole device utilizing a hydraulic magnetic trip mechanism. It is designed for AC applications with a voltage rating of 480V and a current rating of 30A.
This circuit breaker features a compact design and mounts directly onto a 35mm DIN rail, facilitating easy installation in control panels and electrical enclosures. The device offers an interrupting capacity of 10,000A and is built for durability with a mechanical operating life of 10,000 operations.
Key electrical specifications include a dielectric strength of 1500V and an insulation resistance of 100MΩ. The operating temperature range is -40°C to +65°C. Approvals include CE, CSA C22.2 No 235, UL1077, and VDE, ensuring compliance with various industry standards.
The current rating is 30A.
The voltage rating is 480V.
It has 3 poles.
It uses a hydraulic magnetic trip mechanism.
It is designed for DIN rail mounting.
The operating temperature range is -40°C to +65°C.
It is approved by CE, CSA C22.2 No 235, UL1077, and VDE.
