| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Operating Temperature | |
| Voltage | |
| Voltage Rating | |
| Width |
The Weidmüller 9926253525 is a hydraulic magnetic circuit breaker from the 9926 Series. This 3-pole unit is designed for AC applications, with a voltage rating of 480VAC and a maximum current rating of 25A.
Key electrical specifications include an interrupting capacity of 10,000A, dielectric strength of 1500V, and insulation resistance of 100MΩ. The breaker operates within a temperature range of -40°C to +65°C and has a mechanical operating life of 10,000 cycles.
Designed for convenient installation, the 9926253525 features DIN rail mounting. It complies with UL 489, CSA C22.2 No. 5-02, CE, and VDE standards. The breaker type is magnetic with hydraulic delay, and it has a lever actuator.
This circuit breaker is suitable for various industrial and commercial applications requiring reliable overcurrent protection. Its robust construction and adherence to multiple safety standards make it a dependable choice for protecting electrical circuits.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The Weidmüller 9926253525 circuit breaker is rated for 480 VAC.
The maximum current rating for the 9926253525 circuit breaker is 25A.
The 9926253525 circuit breaker has 3 poles.
The 9926253525 uses a Magnetic (Hydraulic Delay) breaker type.
The 9926253525 circuit breaker is designed for DIN rail mounting.
The operating temperature range for the 9926253525 is -40°C to +65°C.
Yes, the 9926253525 is RoHS3 Compliant.
