This Weidmüller 9926 Series circuit breaker, part number 9926253520, is designed for AC applications with a voltage rating of 480V and a current rating of 20A. It features a 3-pole configuration and a magnetic-hydraulic delay trip mechanism, providing reliable overcurrent protection.
The breaker is built for robust performance, with an interrupting capacity of 10,000A and a dielectric strength of 1500V. It is designed for easy installation on a 35mm DIN rail, making it suitable for various industrial and commercial electrical panels.
Key specifications include an operating temperature range of -40°C to +65°C and an operating life of 10,000 mechanical operations. The breaker is approved by CE, CSA, UL, and VDE, ensuring compliance with international standards.
The current rating is 20A.
The voltage rating is 480V.
It has 3 poles.
It uses a Magnetic (Hydraulic Delay) breaker type.
It is mounted on a DIN Rail.
The operating temperature range is -40 to +65°C.
It is approved by CE, CSA C22.2 No 235, UL1077, and VDE.
