The Weidmüller 9926253515 is a branch-rated circuit breaker from the 9926 Series, utilizing a hydraulic magnetic trip mechanism. This single-pole unit is designed for AC applications, operating at 120/240 VAC with a current rating of up to 25A. It features a compact design, measuring just 13 mm wide, and mounts directly onto a 35mm DIN-rail for easy installation.
Key electrical specifications include a voltage rating of 480V and a current rating of 15A. The breaker is a 3-pole unit, providing protection across multiple circuits. It boasts an interrupting capacity of 10,000A, ensuring safety in fault conditions. The operating life is rated for 10,000 mechanical operations, indicating durability.
Environmental and operating conditions are also specified, with an operating temperature range of -40°C to +65°C. The breaker is listed with UL 489, CSA C22.2 No. 5-02, CE, and VDE approvals, confirming its compliance with industry standards. Its mounting type is DIN Rail, making it suitable for standard industrial control panels.
The voltage rating is 480V.
The current rating is 15A.
It has 3 poles.
It uses a Magnetic (Hydraulic Delay) breaker type.
It is mounted on a DIN Rail.
Approval agencies include CE, CSA C22.2 No 235, UL1077, and VDE.
The operating temperature range is -40 to +65°C.
