| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Mounting Type | |
| Number of Poles | |
| Operating Temperature | |
| SVHC Present | |
| Voltage Rating |
The Weidmüller 9926252560 is a branch-rated circuit breaker from the 9926 Series, designed for AC applications. This double-pole unit features a magnetic-hydraulic trip mechanism and is rated for 60A at 480V AC.
Key electrical specifications include an interrupting capacity of 10,000A. The breaker operates within a temperature range of -40°C to +65°C and has a mechanical operating life of 10,000 operations. It is designed for easy installation on a 35mm DIN rail.
This circuit breaker holds multiple approvals, including CE, CSA C22.2 No 235, UL1077, and VDE, ensuring compliance for various applications. It is RoHS3 compliant and has an MSL of 1.
The voltage rating is 480V AC.
The current rating is 60A.
This circuit breaker has 2 poles.
It uses a magnetic (hydraulic delay) breaker type.
It is designed for DIN rail mounting.
The operating temperature range is -40°C to +65°C.
The interrupting capacity is 10,000A.
