| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating (Amps) | |
| Mounting Type | |
| Number of Poles | |
| Operating Temperature | |
| SVHC Present | |
| Voltage Rating | |
| Width |
This Weidmüller 9926252550 is a branch-rated circuit breaker from the 9926 Series, utilizing a hydraulic magnetic trip mechanism. It is a double-pole unit with a current rating of 50A and a voltage rating of 480VAC.
The breaker is designed for easy installation on a 35mm DIN rail, making it suitable for various industrial and control panel applications. Its robust construction and reliable tripping characteristics ensure effective circuit protection.
Key specifications include a 10,000A interrupting capacity and an operating temperature range of -40°C to +65°C. The breaker is listed by UL 489 and CSA C22.2 No. 5-02, CE, and VDE, indicating compliance with relevant safety standards.
The current rating is 50A.
The voltage rating is 480V.
It has 2 poles.
It uses a hydraulic magnetic trip mechanism.
It is designed for DIN rail mounting.
The operating temperature range is -40°C to +65°C.
