| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating (Amps) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Operating Temperature | |
| SVHC Present | |
| Torque | |
| Voltage Rating |
The Weidmüller 9926 Series circuit breaker, model 9926252515, is a double pole, hydraulic magnetic type designed for AC applications. It offers a current rating of 15A and a voltage rating of 480V.
This circuit breaker is built for reliable protection with an interrupting capacity of 10,000A. It mounts conveniently on a 35mm DIN rail, making it suitable for various industrial and control panel installations. The operating temperature range is from -40°C to +65°C.
Key electrical specifications include a dielectric strength of 1500V and an insulation resistance of 100MΩ. The breaker is designed for 10,000 mechanical operations. Wire sizes supported range from 14 AWG to 10 AWG depending on the current rating.
Compliance includes CE, CSA C22.2 No 235, UL1077, and VDE approvals. It is also RoHS3 compliant, MSL 1, and REACH unaffected.
The current rating is 15A.
The voltage rating is 480V.
It has 2 poles.
It uses a Magnetic (Hydraulic Delay) type mechanism.
It is designed for DIN Rail mounting.
The operating temperature range is -40°C to +65°C.
The interrupting capacity is 10000A.
