The Weidmüller 9926 Series circuit breaker, part number 9926252506, is a robust solution for electrical protection. This model is a double-pole, hydraulic magnetic type breaker with a current rating of 6A and a voltage rating of 480VAC.
Designed for easy installation, it features DIN rail mounting, making it suitable for industrial control panels and distribution systems. The breaker is UL 489 listed, CSA C22.2 No. 5-02, CE, and VDE approved, ensuring compliance with stringent safety standards.
Key technical specifications include an interrupting capacity of 10,000A, a dielectric strength of 1500V, and an operating temperature range of -40°C to +65°C. The breaker has a mechanical operating life of 10,000 operations. Wire sizes up to 10AWG are supported for connections.
This circuit breaker is ideal for applications requiring reliable overcurrent protection in AC circuits. Its hydraulic magnetic trip mechanism provides consistent performance across a wide temperature range, without the need for de-rating.
The current rating is 6A.
The voltage rating is 480V.
It has 2 poles.
It uses a magnetic (hydraulic delay) breaker type.
It is designed for DIN rail mounting.
Approval agencies include CE, CSA C22.2 No 235, UL1077, and VDE.
The operating temperature range is -40°C to +65°C.
