The Weidmüller 9926 Series circuit breaker, part number 9926252504, is a double pole unit designed for AC applications. It utilizes a hydraulic magnetic trip mechanism and is rated for 4A current and 480V AC voltage.
This circuit breaker is suitable for DIN rail mounting, making it convenient for panel installations. It offers an interrupting capacity of 10,000A and operates within a temperature range of -40°C to +65°C. The device has undergone approvals including CE, CSA C22.2 No 235, UL1077, and VDE.
Key electrical specifications include a voltage rating of 120/240 VAC at 50/60 Hz and a current range from 0.5A to 25A for the series. The 9926252504 model specifically handles 4A. It also features a dielectric strength of 1500V and an insulation resistance of 100MΩ.
With a mechanical operating life of 10,000 operations, this circuit breaker is built for durability. Wire size compatibility ranges from 10-14 AWG for 0.5-15A ratings and 10 AWG minimum for 20-25A ratings, with a recommended torque of 20 in.-lb.
The current rating is 4A.
The voltage rating is 480V AC.
It is a double pole (2-pole) circuit breaker.
It uses a Magnetic (Hydraulic Delay) breaker type.
It is designed for DIN Rail mounting.
The operating temperature range is -40°C to +65°C.
Approvals include CE, CSA C22.2 No 235, UL1077, and VDE.
