| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Operating Temperature | |
| Voltage Rating | |
| Width |
The Weidmüller 9926 Series circuit breaker, part number 9926252502, is a double pole, hydraulic magnetic type designed for AC applications. It features a current rating of 2A and a voltage rating of 480V.
This circuit breaker is built for reliable operation with a 10,000A interrupting capacity and a wide operating temperature range of -40°C to +65°C. It meets various approval standards including CE, CSA C22.2 No 235, UL1077, and VDE.
The 9926252502 is designed for easy installation, featuring a compact 13mm width and standard DIN rail mounting. Its robust construction ensures 10,000 mechanical operations for long-term service life. The breaker is compliant with RoHS3 standards and has an MSL of 1.
The current rating is 2A.
The voltage rating is 480V.
It is a double pole circuit breaker.
It uses a hydraulic magnetic trip mechanism.
It is designed for DIN rail mounting.
The operating temperature range is -40°C to +65°C.
Approval agencies include CE, CSA C22.2 No 235, UL1077, and VDE.
