| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Operating Temperature | |
| Torque | |
| Voltage Rating |
The Weidmüller 9926 Series circuit breaker, part number 9926252015, is a 2-pole, hydraulic magnetic type breaker designed for AC applications. It features a current rating of 15A and a voltage rating of 240VAC, with an interrupting capacity of 10,000A.
This circuit breaker is built for reliable operation with a hydraulic magnetic trip mechanism, offering a trip characteristic similar to thermal magnetic types without requiring de-rating at elevated temperatures. It mounts conveniently on a 35mm DIN rail, making it suitable for various industrial and control panel applications. The operating temperature range is -40°C to +65°C.
Compliance is certified by UL 489, CSA C22.2 No. 5-02, CE, and VDE. The breaker has a dielectric strength of 1500V and an insulation resistance of 100MΩ. It is designed for a mechanical operating life of 10,000 operations. Wire sizes supported range from 14 AWG to 10 AWG depending on the current rating.
The current rating is 15A.
The voltage rating is 240V.
It has 2 poles.
It uses a magnetic (hydraulic delay) breaker type.
It is designed for DIN rail mounting.
The operating temperature range is -40 to +65°C.
It is approved by CE, CSA C22.2 No 5-02, UL489, and VDE.
