| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating (Amps) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Operating Temperature | |
| Torque | |
| Voltage Rating | |
| Width |
This Weidmüller 9926252005 is a branch-rated, hydraulic magnetic circuit breaker designed for AC applications. It features a 2-pole configuration, a current rating of 5A, and a voltage rating of 240VAC.
The breaker is built with a hydraulic magnetic trip mechanism, offering reliable protection. It mounts directly onto a 35mm DIN rail, making installation straightforward in control panels and enclosures. The unit has an interrupting capacity of 10,000A and an operating temperature range of -40°C to +65°C.
Key specifications include a dielectric strength of 1500V and an insulation resistance of 100MΩ. The operating life is rated for 10,000 mechanical operations. Wire termination is supported for gauges between 14AWG and 10AWG, with a recommended torque of 20 in.-lb.
Compliance certifications include CE, CSA C22.2 No 5-02, UL489, and VDE, ensuring suitability for various industrial and international applications. The compact design, with a width of just 13mm, allows for efficient use of space in electrical installations.
The current rating is 5A.
The voltage rating is 240V.
It has 2 poles.
It uses a magnetic (hydraulic delay) trip mechanism.
It is mounted on a DIN rail.
The operating temperature range is -40°C to +65°C.
Approval agencies include CE, CSA C22.2 No 5-02, UL489, and VDE.
