The Weidmüller 9926252004 is a branch-rated circuit breaker from the 9926 Series, featuring a hydraulic magnetic trip mechanism. This double-pole unit is designed for AC applications, with a voltage rating of 240 VAC and a current rating of 4A.
Key electrical specifications include an interrupting capacity of 10,000A and a dielectric strength of 1500V. The breaker operates reliably within an ambient temperature range of -40°C to +65°C. It is built for durability with an operating life of 10,000 mechanical operations.
For mechanical installation, the 9926252004 features a compact design, measuring just 13 mm wide, and mounts directly onto a 35mm DIN-rail. It supports wire sizes up to 10 AWG and requires a torque of 20 in.-lb for secure connections. The breaker is approved by CE, CSA C22.2 No 235, UL1077, and VDE.
This circuit breaker is compliant with RoHS3 standards and has an MSL rating of 1. It is suitable for various industrial and commercial applications requiring reliable overcurrent protection.
240VAC.
4A.
10000A.
-40°C to +65°C.
2 poles.
DIN rail mounting.
Magnetic (Hydraulic Delay).
