The Weidmüller 9926252003 is a branch-rated, hydraulic magnetic circuit breaker designed for AC applications. This double-pole unit features a 3A current rating and a 240VAC voltage rating, making it suitable for various protection needs.
Key specifications include a 10,000A interrupting capacity and a wide operating temperature range of -40°C to +65°C. The breaker is built with a magnetic-only trip mechanism, offering a trip characteristic similar to thermal magnetic types without requiring de-rating at elevated temperatures. It is 13mm wide and mounts directly onto a 35mm DIN rail, facilitating easy installation in control panels and enclosures.
This circuit breaker holds multiple approvals, including UL 489 listed, CSA C22.2 No. 5-02, CE, and VDE, ensuring compliance with international standards. Its robust construction and reliable tripping performance make it a dependable choice for overcurrent protection in industrial and commercial settings.
The current rating is 3A.
The voltage rating is 240V.
It has 2 poles.
It uses a Magnetic (Hydraulic Delay) breaker type.
It is mounted on a DIN Rail.
The operating temperature range is -40°C to +65°C.
The approval agencies are CE, CSA C22.2 No 235, UL1077, VDE.
