| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Mounting Type | |
| Number of Poles | |
| Operating Temperature | |
| Voltage Rating | |
| Width |
The Weidmüller 9926 Series circuit breaker, part number 9926252001, is a double-pole, branch-rated AC version designed for reliable circuit protection. It features a magnetic-hydraulic trip mechanism with a delay characteristic similar to thermal-magnetic types, ensuring consistent performance across operating temperatures.
This breaker is rated for 240 VAC and a current of 1A. It offers an interrupting capacity of 10,000A and is designed for easy mounting on a 35mm DIN rail, making it suitable for various industrial and commercial applications. The compact design, with a width of just 13mm per pole, allows for space-saving installations.
Key specifications include a wide operating temperature range from -40°C to +65°C and a mechanical operating life of 10,000 operations. It is compliant with CE, CSA C22.2 No. 5-02, UL 489, and VDE standards, indicating its suitability for international markets.
The 9926252001 circuit breaker has a voltage rating of 240 VAC.
The current rating for the 9926252001 circuit breaker is 1A.
The 9926252001 circuit breaker has 2 poles.
The 9926252001 circuit breaker uses a Magnetic (Hydraulic Delay) trip mechanism.
The 9926252001 circuit breaker is designed for DIN Rail mounting.
The operating temperature range for the 9926252001 circuit breaker is -40°C to +65°C.
The 9926252001 circuit breaker has an interrupting capacity of 10,000A.
