| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Mounting Type | |
| Number of Poles | |
| Operating Temperature | |
| SVHC Present | |
| Voltage Rating | |
| Width |
The Weidmüller 9926251940 is a single-pole circuit breaker from the 9926 Series, utilizing a hydraulic magnetic trip mechanism. It is rated for a maximum current of 40A and an operating voltage of 80VDC.
This circuit breaker features a compact design, measuring just 13 mm wide, and is designed for easy mounting on a 35mm DIN rail. It offers an interrupting capacity of 10,000A and has an operating life of 10,000 mechanical operations. The operating temperature range is -40°C to +65°C.
Key approvals include CE, CSA C22.2 No 235, UL1077, and VDE, indicating its suitability for various industrial applications. The lever actuator provides a clear means of operation.
Compliance information indicates RoHS3 compliance, MSL 1, and REACH unaffected status, though these are noted as having low confidence and require verification.
80 V DC.
40 A.
1 pole.
Magnetic (Hydraulic Delay).
10,000 A.
-40°C to +65°C.
DIN Rail.
