| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Operating Temperature | |
| Voltage Rating | |
| Width |
The Weidmüller 9926251904 is a single-pole circuit breaker from the 9926 Series, utilizing a hydraulic magnetic trip mechanism. It is designed for AC and DC applications, with a voltage rating of 80VDC and a current rating of 4A.
This breaker offers a 10,000A interrupting capacity and is built for reliability with 10,000 mechanical operations. It operates within a temperature range of -40°C to +65°C and features a compact 13mm width.
The 9926251904 is suitable for DIN rail mounting, making it easy to integrate into control panels and electrical enclosures. Its lever actuator provides a clear visual indication of the circuit status.
Compliance includes CE, CSA C22.2 No 235, UL1077, and VDE approvals. The RoHS status is listed as RoHS3 Compliant, MSL is 1 Unlimited, and REACH status is Unaffected, though these compliance details carry a low confidence rating.
The voltage rating is 80V DC.
The operating temperature range is -40°C to +65°C.
The current rating is 4A.
The interrupting capacity is 10,000A.
It uses DIN rail mounting.
It has a lever actuator.
The operating life is 10,000 mechanical cycles.
