| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Operating Temperature | |
| Storage Temperature | |
| Tape & Reel | |
| Voltage Rating |
The Weidmüller 9926251550 is a single-pole branch-rated circuit breaker from the 9926 Series. It utilizes a magnetic-hydraulic trip mechanism for reliable operation.
This circuit breaker is rated for a maximum voltage of 240V AC and a current rating of 50A. It features a 10,000A interrupting capacity and an operating life of 10,000 mechanical operations. The operating temperature range is -40°C to +65°C.
Designed for convenient installation, the 9926251550 mounts directly onto a 35mm DIN rail. Its approval agencies include CE, CSA C22.2 No 235, UL1077, and VDE, ensuring compliance with various industry standards.
Key electrical specifications include an insulation resistance of 100MΩ and a dielectric strength of 1500V at 50/60Hz. The breaker type is magnetic (hydraulic delay) with a lever actuator.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The current rating is 50A.
The voltage rating is 240V.
It has 1 pole.
It uses a magnetic (hydraulic delay) trip mechanism.
It is designed for DIN rail mounting.
Approval agencies include CE, CSA C22.2 No 235, UL1077, and VDE.
The operating temperature range is -40°C to +65°C.
