The Weidmüller 9926251510 is a single-pole magnetic hydraulic circuit breaker designed for supplementary protection in industrial control panels and equipment. It is rated for 10A continuous current at 240VAC and provides an interrupting capacity of 10,000A.
This breaker uses a hydraulic-magnetic trip mechanism, which offers precise overcurrent protection with minimal temperature sensitivity. The lever actuator allows for manual on/off control and visible trip indication. It is designed for DIN rail mounting, simplifying installation in standard enclosure layouts.
The device is certified to CE, CSA C22.2 No 235, UL1077, and VDE standards, making it suitable for use in North American and European markets. It operates reliably across a wide temperature range of -40 to +65°C.
The voltage rating is 240VAC.
The current rating is 10A.
It is a magnetic hydraulic delay circuit breaker.
The operating temperature range is -40 to +65°C.
It is mounted on a DIN rail.
The interrupting capacity is 10,000A.
