| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Operating Temperature | |
| Voltage Rating | |
| Width |
This Weidmüller 9926 Series circuit breaker, part number 9926251508, is a single-pole, hydraulic magnetic type designed for AC applications. It offers a current rating of 8A and a voltage rating of 240VAC, with an interrupting capacity of 10,000A.
The breaker is built for reliable operation within an ambient temperature range of -40°C to +65°C and has a mechanical operating life of 10,000 cycles. Its compact design features a width of 13mm and is suitable for mounting on a 35mm DIN-rail.
Approvals include CE, CSA C22.2 No 235, UL1077, and VDE, ensuring suitability for various industrial and commercial applications. The breaker utilizes a lever actuator for operation.
Key electrical specifications include a dielectric strength of 1500V and an insulation resistance of 100 MΩ. It is designed with a magnetic-only trip mechanism, offering a trip characteristic similar to thermal magnetic types without requiring de-rating at elevated temperatures.
240VAC.
8A.
10,000A.
-40 to +65°C.
DIN Rail.
Lever.
1.
