| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating (Amps) | |
| Mounting Type | |
| Number of Poles | |
| Operating Temperature | |
| SVHC Present | |
| Torque | |
| Voltage Rating | |
| Width |
The Weidmüller 9926251016 is a single-pole branch-rated circuit breaker from the 9926 Series. It features a hydraulic magnetic trip mechanism and is rated for 16A at 120V AC, 50/60 Hz.
This circuit breaker is designed for reliable operation with a 10,000A interrupting capacity and a wide operating temperature range of -40°C to +65°C. It offers 10,000 mechanical operating cycles for durability.
Mounting is simplified with a standard DIN rail interface, making it suitable for various industrial and control panel applications. The breaker is compliant with CE, CSA C22.2 No. 5-02, UL 489, and VDE standards, ensuring broad applicability.
Key specifications include a 16A current rating, 120V voltage rating, and a magnetic-hydraulic delay type. The compact 13mm width allows for space-saving installations.
The current rating is 16A.
The voltage rating is 120V AC.
It is a single-pole (1-pole) circuit breaker.
It uses a magnetic (hydraulic delay) breaker type.
It is designed for DIN rail mounting.
It is approved by CE, CSA C22.2 No 235, UL1077, and VDE.
The operating temperature range is -40°C to +65°C.
