| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Operating Temperature | |
| Torque | |
| Voltage Rating | |
| Width |
The Weidmüller 9926 Series circuit breaker, part number 9926251005, is a single-pole unit with a magnetic-hydraulic trip mechanism. It is rated for a current of 5A and an operating voltage of 120V AC.
This breaker features a compact design, measuring just 13mm wide, and is suitable for mounting on a standard 35mm DIN rail. It offers an interrupting capacity of 10,000A and has undergone testing and certification by major agencies including UL 489, CSA C22.2 No. 5-02, CE, and VDE.
The operating temperature range for this series is -40°C to +65°C. The breaker is built for durability with an operating life of 10,000 mechanical operations. Wire sizes from 14 AWG to 10 AWG are supported for connections, with a recommended torque of 20 in.-lb.
This model is compliant with RoHS3 standards and has a Moisture Sensitivity Level (MSL) of 1. It is suitable for various industrial and commercial applications requiring reliable overcurrent protection.
The current rating is 5A.
The voltage rating is 120V AC.
It is designed for DIN rail mounting.
It uses a magnetic (hydraulic delay) breaker type.
It is approved by CE, CSA C22.2 No 5-02, UL489, and VDE.
The operating temperature range is -40°C to +65°C.
