| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Operating Temperature | |
| Torque | |
| Voltage Rating |
The Weidmüller 9926251004 is a 1-pole magnetic (hydraulic delay) circuit breaker designed for overcurrent protection in industrial and commercial applications. It is rated for 4A at 120VAC (50/60Hz) and offers a high interrupting capacity of 10,000A.
This circuit breaker features a lever actuator and mounts on a standard DIN rail. It is approved under CE, CSA C22.2 No 235, UL1077, and VDE standards, ensuring compliance with international safety requirements. The operating temperature range is -40°C to +65°C, and the mechanical operating life is rated for 10,000 operations.
Electrical specifications include a dielectric strength of 1500V at 50/60Hz and an insulation resistance of 100MΩ. The terminal torque is 20 in.-lb, and wire sizes range from 14-10 AWG for 0.5-15A ratings and 10 AWG minimum for 20-25A ratings.
The voltage rating is 120VAC (50/60Hz).
The current rating is 4A.
It is a magnetic (hydraulic delay) circuit breaker.
The operating temperature range is -40°C to +65°C.
It mounts on a DIN rail.
