| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating (Amps) | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Operating Temperature | |
| Voltage Rating |
The Weidmüller 9926251003 is a single pole circuit breaker from the 9926 Series, utilizing a magnetic-hydraulic delay mechanism for reliable operation. It is rated for 3A current and 120V AC voltage, making it suitable for various branch circuit protection applications.
This circuit breaker is designed for easy installation on a 35mm DIN rail, a common standard in industrial and control panel environments. Its compact design and lever actuator contribute to efficient panel space utilization and user-friendly operation. The breaker boasts an interrupting capacity of 10,000A and is approved by CE, CSA C22.2 No 235, UL1077, and VDE, ensuring compliance with international standards.
With an operating temperature range of -40°C to +65°C and a mechanical operating life of 10,000 operations, the 9926251003 is built for durability and consistent performance in demanding conditions. It also meets RoHS3 compliance and has an MSL of 1.
The current rating is 3A.
The voltage rating is 120V.
This is a single pole circuit breaker.
It uses a magnetic (hydraulic delay) breaker type.
It is designed for DIN rail mounting.
It is approved by CE, CSA C22.2 No 235, UL1077, and VDE.
The operating temperature range is -40°C to +65°C.
